Installation
! Keep this booklet for consultation at any time. In the
event of sale, transfer of the machine or of the owner
ensure that the booklet is kept with the machine so that
the new owner is informed of the operating instructions
and warnings.
! Read all instructions carefully. They contain important
information regarding installation, operation and safety.
Positioning
! Packaging is not a toy for children and should
be disposed of in accordance with regulations for
separated waste collection (see Precautions and
recommendations).
! Installation must be carried out in compliance with
these instructions by professionally qualified personnel.
Incorrect installation may cause damage to persons,
animals and/or objects.
Built-in installation
To ensure the correct functioning of the appliance, the
cabinet must have the right characteristics:
• the panels next to the coffee machine must be in
heat-resistant material;
• veneered wood cabinets should be joined using
glues resistant to 100°C/212°F and must be steam-
resistant;
• for all installations of built-in coffee machines
cabinets should have the following dimensions:
! Once the appliance has been encased, there must
be no contact possible with electrical parts. Declared
consumption values shown on the rating plate are
measured on the basis of this type of installation.
Ventilation
To ensure good ventilation, remove the rear panel of the
cabinet.
It is recommended to install the coffee machine so that
it is resting on a continuous surface with an opening of
at least 1¾” x 21¼” (45 x 540 mm) in the base.
Centring and fixing
To centre the coffee machine, position the shims
beneath the holes in the outer structure of the machine.
! All shims must be attached so that they ensure perfect
stability of the machine.
To attach the shims to the cabinet proceed as follows:
• remove the drip tray
from the machine;
• fasten the 2 wood
screws in the 2 holes
located to the rear of the
base.
• remove the lower
plastic protection;
