Installation
8
Oven Assembly
DECK INSTALLA TION
1. Remove the decks from the carton package.
NOTE: Handle cordierite shelves carefully to
avoid damage.
2. Open the oven door and remove the center
element assembly. The assembly is removed
by puling forward and unplugging.
3. Install one of the decks in the bottom position.
The deck should rest on t he angles above the
element and should be positioned in contact
with the linerback.
4. Install the o ther deck in the center element as-
sembly on a flat surface. Reinstall the center
deck and element assembly in the oven. The
assembly is supported on four angl e s uppo rts.
Bottom
Deck
Top Deck
Center
Element
Figure 6
LEVELING THE OVEN
1400 Series ovens are equipped with NSF listed
adjustable sanitary legs.
1. Level the oven side to side and front to back
by placing a spirit level on the base frame o f
the lower section.
2. Adjust the leg feet in or out as necessary.
