Installation
7
Oven Assembly
STACKING THE OVENS
Bottom Oven
1. Install the legs, as directed.
2. Attach the stacking rail to the back of the con-
trol compartment.
To p O ve n( s)
1. Resttheovenonit’sback.Installanoven
alignment pin into each of the four holes in the
bottom of the oven.
2. Attach the heat shield brackets to the bottom
of the control box of the upper oven with the
screws provided.
3. Carefully lift the upper oven off the pallet and
placeitontheloweroven.Besurethealign-
ment pins are inserted into the holes in the top
of the lower oven.
4. Slide the heat shield into the brackets.
Heat Shield
Brackets
Top Oven
Heat Shield
Stacking Rail
Bottom Oven
Alignment Pin
Figure 5
