Crosley 241824400 Refrigerator User Manual



14
AUTOMATIC ICE AND WATER DISPENSER
AUTOMATIC ICE & WATER DISPENSER OPERATING INSTRUCTIONS
Features may vary according to model.
1 2
3 4
5
6
7
8
9
EXTREME To freeze food at a faster rate to preserve freshness, push the Touch Pad for 3-5 seconds to
FREEZE activate this feature. A green light will appear above the Touch Pad. Push the Touch Pad again
for 3-5 seconds to deactivate.
EXTRA To increase ice production for special occasions, such as parties, push the Touch Pad for
ICE 3-5 seconds to activate this feature. A green light will appear above the Touch Pad. Push the
Touch Pad again for 3-5 seconds to deactivate. Extra Ice should produce 25% to 50% more ice
every 24 hours.
CUBE Press the CUBE Touch Pad to get cubed ice. A green light will appear above the Touch Pad.
Press glass against ICE dispensing paddle as far up as possible to catch all ice.
CRUSH Press the CRUSH Touch Pad to get crushed ice. A green light will appear above the Touch Pad.
Press glass against ICE dispensing paddle as far up as possible to catch all ice.
LIGHT Press the LIGHT Touch Pad to turn on dispenser light. Press again to turn the light off.
The light also turns on automatically when ice and/or water is dispensed. Replace light bulb with
an appliance bulb of the same wattage.
FILTER The FILTER STATUS indicator light above the Touch Pad will light up each time the dispenser
STATUS is used. The following filter light indications are:
Green The filter is still operating within its specified life cycle.
Amber The filter has reached approximately 80% of its useful life. This is the recommended time
to purchase a replacement filter.
Red The filter is 100% used up. Change the filter as soon as possible.
After the filter cartridge has been changed, press and hold the FILTER RESET Touch Pad for
10-15 seconds.
NOTE: The Green, Red and Amber lights will flash when reset is completed.
LOCK The Ice & Water Dispenser can be locked out to prevent unwanted use.
To Lock Out Press the LOCK Touch Pad for 3-5 seconds. A Red light will appear above
the Touch Pad.
To Unlock Press the LOCK Touch Pad for 3-5 seconds until the Red light above the
Touch Pad goes out.
WATER To operate the water dispenser, press a glass against the WATER dispensing paddle . To
stop dispensing water, pull the glass away from the dispensing paddle . Dispensed water is not
cold. For colder water, add crushed ice or cubes before dispensing water. A drip tray located at
the base of the dispenser catches small spills and allows them to evaporate. This drip tray is
removable and dishwasher safe. Do not pour water and excess ice in this area because there
is no drain.
1
1
2
3
4
7
7
9
8
8
5 5
6
6
2
9
