AUTOMATIC ICE AND WATER DISPENSER
ICE PRODUCTION: WHAT TO EXPECT
How Much Ice Will a Side Mounted Ice Maker
Produce in 24 Hours?
A side mounted ice maker will produce 4 to 4.5 pounds of
ice every 24 hours, depending on usage conditions. Ice is
produced at a rate of 8 cubes every 75 to 90 minutes.
How Much Ice Will a Rear Mounted Ice Maker
Produce in 24 Hours?
A rear mounted ice maker will produce 3 to 4 pounds of ice
every 24 hours, depending on usage conditions. Ice is
produced at a rate of 8 cubes every 75 to 90 minutes.
ICE AND WATER DISPENSER FEATURES
The ice and water dispenser conveniently dispenses chilled
water, and ice cubes or crushed ice, depending on the model.
To operate the ice dispenser, select the ice option desired
using the touchpad. Press a glass against the dispensing
paddle as far up as possible to catch all ice. To stop
dispensing ice, pull glass away from dispensing paddle. Do
not remove the glass until the ice has completely dispensed.
Complete instructions for the dispenser operation are attached
to the inside of the freezer door (some models).
ICE DISPENSER TIPS
CA CA
CA CA
CA
UTIONUTION
UTIONUTION
UTION
If the dispensing paddle is pushed for more than four
minutes, the dispenser motor may overload and stop.
The overload protector will reset automatically after
three or four minutes.
• Ice cubes stored too long may develop an odd flavor.
Empty the ice container and ensure that the ice maker is
on (see previous page). The ice maker will then produce
more ice.
• Occasionally shake the ice container to keep ice
separated.
• If a large quantity of ice is needed at one time, it is best
to remove cubes directly from the ice container.
• Stop the ice maker when cleaning the freezer and during
vacations.
• If the ice maker will be turned off for a long period of
time, turn the water supply valve to a closed position.
CLEANING THE ICE DISPENSER
Clean the ice dispenser and ice container at regular intervals,
particularly before you take a vacation or move, or if the ice
dispenser sticks.
• Stop ice production on side-mounted ice maker by
raising wire signal arm to the UP position. Stop ice
production on rear-mounted ice makers by pressing the
ice maker’s On/Off power switch to the Off (O) position.
• Remove ice container by lifting up and out. Empty and
carefully clean the container with mild detergent. Rinse
with clear water. Do not use harsh or abrasive cleaners.
Allow ice container to dry completely before replacing in
the freezer.
• Remove ice chips and clean the shelf and chute that
supports the ice container.
• Replace the ice container. Resume ice production on
side-mounted ice makers by lowering the wire signal
arm to the DOWN position. Resume ice production on
rear-mounted ice makers by pressing the ice maker’s
On/Off power switch to the On (I) position.
WARNING WARNING
WARNING WARNING
WARNING
Do not use the ice chute as a handle when removing or
replacing the ice storage bin. Surfaces there may be
sharp. Do not put fingers up ice chute. Surfaces there
may be sharp.
IMPOR IMPOR
IMPOR IMPOR
IMPOR
TT
TT
T
ANTANT
ANTANT
ANT
When removing or replacing the ice bin, DO NOT rotate the
auger in the ice bin. If the auger is accidentally rotated, you
must realign the auger by turning it in 90º turns until the ice
bin fits into place with the drive mechanism. If the auger is
not properly aligned when replacing the ice bin, the
refrigerator will only dispense
Crushed Ice
. The freezer
door may also not close properly causing warm air to leak
into the freezer.
CA CA
CA CA
CA
UTIONUTION
UTIONUTION
UTION
NEVER use an ice pick or similar sharp instrument to
break up the ice. This could damage the ice storage bin
and dispenser mechanism.
• An extended power failure (one hour or longer) causes
ice cubes in the ice storage bin to melt and freeze
together and jam the dispenser mechanism.
• The ice dispenser is not used frequently. Ice cubes will
freeze together in the bin and jam the dispenser
mechanism. Remove the ice storage bin and shake to
loosen the cubes.
