15
VENTILATION REQUIREMENTS
The appliance must have adequate ventilation to
ensure correct operation.
The diagram shows the ventilation requirements when
installed:
A* Under a worktop or cupboard
B freestanding
* The clearance space of 10cm above the appliance
may be reduced to 5cm providing a clearance space
of 2.5cm is left either side of the appliance.
LEVELLING
The appliance MUST be level. Level the appliance by
adjusting the two adjustable feet (1) at the front of the
appliance.
If required the washer (2) can be removed.
DOOR REVERSAL
Should you wish to reverse the direction that the door
opens, follow the instructions and diagrams below.
Ensure that the appliance is disconnected from
the electricity supply before reversing the door.
To reverse the bottom hinge assembly proceed as
follows:
Tilt the appliance backwards, resting the top edge
of the appliance on a stool or something similar.
Unscrew the adjustable feet situated on both sides
at the front (2 pieces). Remove the lower door
hinge plate by unscrewing the 3 retaining screws.
Remove the hinge pin from the bottom of the door.
Slot the hinge pin into the hole in the hinge pin plate
and relocate the hinge pin assembly to the opposite
location and refit using the retaining screws.
Return the cabinet to an upright position.
