Installation
VERIFY PACKAGE CONTENTS
Unpack hood and check contents.
You should receive:
1 - Hood
1 - Decorative Flue Assembly
1 - Support Frame
1 - Duct Collar
1 - Parts Bag containing:
8 - Washers ø 6.4
4 - Washers ø 4.5
4 - Lag Bolts
8 - Mounting Screws (3.9 X 9.5mm Pan Head)
4 - Hex Nuts
1 - Installation Instructions
2 - Warranty Cards
Figure 4
4 Lag Bolts
(6x70mm)
4 HEX NUTS
SUPPORT
FRAME
DECORATIVE
FLUE
8 MOUNTING SCREWS
(3.9 x 9.5mm Pan Head)
DUCT COLLAR
8 WASHERS
ø6.4
4 WASHERS
ø4.5
