BID80 SERIES GAS FRYERS
CHAPTER 9: PARTS LIST
9-3
9.2 Cabinetry and Related Components (cont.)
ITEM PART # COMPONENT
1 211-2532 Side, Cabinet- Left
2 210-1365 Duct, Door Access
3 212-2532 Side, Cabinet- Right
4 200-2683 Back, Cabinet
* 200-1376 Bracket, Restraining
* 200-3635SP Crossbrace, Cabinet Back, Lower
5 823-3512 Flue Cap
6 824-0954 Box, Component (Wireway Control)
7 824-0986 Top Cap
8 200-1301 Pin, Door
9 200-2688 Panel, Inner- Door
* 810-0179 Plug, Handle-Screw Access
* 816-0529 Bumper, Rubber (Self-Adhesive)
* 809-0193 Bushing, Nylon (Door Pin)
10 210-1151 Panel, Outer- Door
11 810-2105 Handle, Chrome (With Screws)
12 810-0066 Magnetic Catch, Door
13 200-3403 Base, Lower Frame
* 200-3461 Cover, Access- Lower Frame Base (2 Required)
14 823-3745 Base, Upper Frame
15 823-3724 Channel, Leg Support (Right and Left)
16 200-3459 Base, Leg Channel
17 210-3588 Slide, Front- Filter Pan
18 823-3751
Slide, Rear Left- Filter Pan
19 823-3752
Slide, Rear Right- Filter Pan
20 200-1675 Bracket, Lower Door Hinge
21 210-2870 Plate, Door Magnet
22 810-0356 Caster, Without Brake
23 810-0357 Caster, With Brake
* Not Illustrated
