BID80 SERIES GAS FRYERS
CHAPTER 9: PARTS LIST
9-9
9.6 Frypot, Burners and Related Components (cont.)
ITEM PART # COMPONENT
1 823-3396SP Frypot, SS- 1-½" Drain System
2 200-2707 Shield, Heat- Front
3 200-2734 Bracket, Burner Mounting
4 810-2151 Burner, Left
5 810-2149 Burner, Center
6 810-2150 Burner, Right
7 810-2365 Orifice #56 (1.19 mm)
8 810-2072 Manifold, Gas
9 200-1314 Support, Manifold- Left and Right
10 813-0031 Bushing, Hex- ½ to ¾" NPT BM
11 813-0607 Nipple, ½ x 23-½" NPT BM
12 813-0165 Elbow, Street- 90° ½" NPT BM
13 807-3628 Valve, Gas- Honeywell ½ x ¾" 10" W.C.
14 813-0112 Nipple, ¾ x 2" NPT BM
15 813-0066 Elbow, 90° NPT BM
16 813-0635 Nipple, ¾ x 2-¼" NPT BM
17 813-0174 Union, ¾" NPT BM
18 813-0109 Nipple, ¾" x Close NPT BM
19 813-0168 Elbow, Street- 90° ¾" NPT BM
20 813-0359 Coupling, ¾ x 1.62" NPT
21 810-0705 Gas Line, Pilot- One Piece- 23"
22 807-1553 Pilot Assembly, LP
23 807-1310 Sensor, Flame
24 807-1315 Cable, Ignition
25 810-2155 Pilot Burner Assembly, Trailing Pilot-LP
26 810-0703 Gas Line, Trailing Pilot- One Piece- 17-½"
27 810-2138 Valve, Trailing Pilot
28 200-1316 Shield, Flue
29 200-1347 Front, Flue
30 200-1349 Rear, Flue
* 809-0167 Screw, Sheet Metal- 10A x 5/8"
31 823-3513 Diffuser, BID80
* Not Illustrated
