BID80 SERIES GAS FRYERS
CHAPTER 9: PARTS LIST
9-5
9.3 Computer and Related Components (cont.)
ITEM PART # COMPONENT
1 210-3463 Panel, Control- BID80
2 106-2334 Computer, CMIII.5- BID80
3 823-3433 Bezel, Computer
4 807-3611 Relay, 24 Amp (Filter Circuit)
5 807-0979 Transformer, 208/240V - 12V- Secondary
6 807-1999 Transformer, 208/240V – Dual Voltage
7 806-4549 Board, Interface
8 807-0833 Relay, 5 Amp (Latch Relay- Interface Board)
9 806-2071 Harness, Wire- Computer To Interface Board
10 810-1164 Block, Terminal (Power In)
* 816-0217 Insulation, Terminal Block
11 806-7179SP Sound Device
12 807-3680 Thermostat, High-Limit- 450°F Manual Reset
* 810-2046 Spring, Spacer- High-Limit Bulb
13 807-3580 Switch, Rocker- Filter Pump Bypass Switch
14 807-3538 Circuit Breaker, 5 Amp
15 807-1321 Holder, Fuse- Buss Fuse
* 807-3592 Fuse, 2 Amp
16 106-1424 Probe Assembly, Sensor
* 210-1386 Clamp, Probe Bulb and High-Limit Bulb
* 810-2164 Spring, Spacer- Probe Bulb
* 809-0448 Clip, Tinnerman (Sensor Probe and High-Limit Probe Clamp)
* 809-0360 Screw, Probe/H-Limit Bulb Clamp- #8 x 3/8 Slotted Hex Head
* Not Illustrated
