Safety Instructions Operating Instructions Care and Cleaning Installation Instructions Troubleshooting Tips Customer Service
17
Read these instructions completely and carefully.
Preparation
■ Remove all tape and packaging.
■ Take the accessory pack out of the oven.
■ Check to be sure that no range parts have come
loose during shipping.
Dimensions and Clearances
IMPORTANT: Save these instructions for the
local electrical inspector’s use.
■ See the illustration below for all rough-in and
spacing dimensions. These dimensions must be
met for safe use of your range.
■ The range may be placed with 1
3
⁄4″ clearance at
the back wall and 0″ clearance (flush) at side
walls of the range if the front edges of the range
side panels stick out beyond the cabinet fronts
at least 1/4″.
■ To eliminate the risk of burns or fire when
reaching over hot surface elements, cabinet
storage space above the cooktop should be
avoided. If cabinet storage space is to be
provided above the cooktop, the risk can be
reduced by installing a range hood that sticks
out at least 5″ beyond the front of the cabinets.
Cabinets installed above a cooktop may be no
deeper than 13″.
Rear
Oven
oven
surface
Rear
Front
B
A
C
From combustible
walls above cooking
surface
Models A B C
20
″
Wide 20
″
20
3
⁄
8
″
2
″
24
″
Wide 24
″
24
3
⁄
8
″
0
″
36″
40
1
⁄4″
From bottom
of range to
strain relief
clamp
Surface
mount
outlet
Flush
mount
outlet
5
1
⁄4″
40
1
⁄2″
2
1
⁄2″
2″
5″
5″
5″
34″
30″
24″
18″ min.
13″ max.
36″
max.
25
1
⁄2″ from
wall to front
of control
panel
*Depth including handle: 25
9
⁄16″.
*Depth to front of control knobs: 26
1
⁄8″.
24″
