Title: B. Refrigeration Circuit Model: One Section: CF3B-FS, CF3B-HS
Index
No. Description
Material or
Model Number Part Number
Required Number
A-5
Refrigeration Circuit
Order Assembly Parts Individually
1A2157A01 1
1 Compressor 4A3808-01 1
1a Rubber Grommet 4A1452-01 4
1b Compressor Clip 4A4867-01 4
1c Screw 4A4993-01 4
2 Terminal Cover (includes clip) 4A3112-01 1
3 Cord Relief 4A1454-01 2
4 Start Relay 4A3113-01 1
5 Start Capacitor 240MFD,
125/165VAC
4A2134-03 1
6 Condenser 2A6415-01 1
7 Condenser Shroud 3A6631G01 1
8 Condenser Fan Guard 2A5187-01 1
8a Truss Head Screw 5×12, SS 7C32-0512 4
9 Condenser Fan Motor 4A4869-01 1
9a Self-Locking Nut 8-32 7N21I0832 4
10 Condenser Fan Blade 3A5817-01 1
11 Condensate Pan 2A5218-01 1
12 Condensate Coil Strap 3A5672-01 1
13 Condensate Coil 3A6465G01 1
14 Evaporator 2A6463-01 1
15 Evaporator Bracket 3A5492-01 1
15a Screw 4A4993-02 2
16 Evaporator Drain Bracket 3A5495-01 1
17 Defrost Thermistor 4A4865-01 1
18 Defrost Heater 2A5378-01 1
19 Defrost Thermostat 4A0954-02 1
20 Evaporator Mount Bracket 3A5493-01 2
20a Screw 4A4993-02 4
21 Evaporator Fan 4A5343-01 2
21a Flat Washer 7W22-0500 8
21b Split Lock Washer 7L22-0500 8
21c Tapping Screw 4A3883-01 8
22 Evaporator Fan Bracket 2A6424-01 1
22a Screw 4A4993-02 5
23 Drier 4A1113-01 1
24 High-Pressure Switch 4A2516-02 1
25 Expansion Valve 4A5344-01 1
26 Expansion Valve Cover (A) 3A0372-01 1
27 Expansion Valve Cover (B) 3A0372-02 1
28 Expansion Valve Bulb Holder 3A0107-01 1
29 Clamp 443461-01 1
30 Condensate Water Pump
(includes Float Switch)
3A6339G01 1
31 PVC Tubing L=350 7716I1438 1
32 R404A Label 4A0960-01 1
33 Cabinet Thermistor 4A4864-01 1
34 Condenser Block 3A6579-01 1
