Title: E. Door-Left Hinged Model: Half Solid: CR3B-HS, CF3B-HS
Index
No. Description
Material or
Model Number Part Number
Required Number
A-5
Door-Left Hinged; Half Solid
Order Assembly Parts Individually
2A6256A01 1
1 Hinge Bracket 3A6249-01 2
1a Countersunk Screw 5×20, SS 7C42-0520 6
2 Thrust Washer 4A5233-01 2
3 Lock Washer 4A5231-01 2
4 Screw 4A5230-01 2
5 Hinge Bracket (L) 3A6250G02 1
5a Countersunk Screw 5×20, SS 7C42-0520 2
6 Thrust Washer 4A5234-01 1
7 Half Door Lock 4A5249-01 1
7a Bolt 5×16, SS 449879-08 1
8 Truss Head Screw (ller screws) 5×10, SS 7C32-0510 11
9 Door Assembly (UR, LL)
(includes items 10 through 13)
2A6252G01 1
10 Truss Head Screw (ller screws) 5×10, SS 7C32-0510 2
11 Hinge Cartridge 3A6258-01 1
11a Countersunk Screw 5×20, SS 7C42-0520 2
12 Bearing 4A5232-01 1
13 Door Gasket 2A5192-02 1
14 Door Assembly (LR, UL)
(includes items 15 through 18)
2A6253G01 1
15 Truss Head Screw (ller screws) 5×10, SS 7C32-0510 2
16 Hinge Cartridge 3A6258-01 1
16a Countersunk Screw 5×20, SS 7C42-0520 2
17 Bearing 4A5232-01 1
18 Door Gasket 2A5192-02 1
