Series 322 Ice Cube Machine Installation Instructions
© 2004-2007, IMI Cornelius Inc. - 1 - Publication Number: 166240006INS
INSTALLATION MANUAL
Series 322 Ice Cube Machine
SPECIFICATIONS
UNPACKING
1. Uncrate machine and/or bin by removing the staples from around the bottom of cardboard crate and
lift off.
2. Remove bolts fastening the crate skid to the bottom of the unit. If auxiliary legs have been
purchased for the bin, they should be installed at this time.
FIGURE 1
Net weight 122 lbs.
Shipping weight 138 lbs.
Compressor Copeland 4170 BTU/Hr.
Refrigerant R404A
Electrical
Freeze cycle amps draw 15.0
Time delay fuse retains (amps) 20.0
Minimum circuit ampacity (amps) 20.0
Power supply (single phase) 115V/60 Hz
Plumbing connections
Inlet water supply Max. pressure 50 PSI 3/8” SAE MFL Ftg
Bin drain Through bin
Waste water (from water-cooled models) Two 3/8” SAE MFL fittings
Pump out drain connection 1/2” ID tubing
Air In
15.00
C
A
6 ft electrical
cord
14.75
2.00
1.00
22.00
5.00
23.50
21.00
7.00
16.38
11.25
5.00
23.50
2.25
2.75
.75
Front
Opening
22.00
F
E
B
A. Water inlet
B. Pump out drain
C. Electrical connection
D. Condensate drain
E. Condenser (water out) (W/C only)
F. Condenser (water in) (W/C only)
Note: Must use 20 amp receptacle
D
Release Date: February
www.cornelius.com Revision: A
