Oven Controls
Changing Oven Temperature Display
The oven control is preset for temperatures in °F (Fahrenheit)
when shipped from the factory. The control can be changed to
display either Fahrenheit or Celsius.
To change the display to F (Fahrenheit) or C (Celsius):
1. Press and hold Broil for 6 seconds.
2. Once F (or C) appears in the display, press Self Clean to
toggle between Fahrenheit and Celsius temperature display
modes (Figure 6).
3. Press to accept choice.
Important note:
The oven temperature display cannot be changed during the
cooking process or if a Delay Start has been set or Self Clean is
active.
Setting Silent or Audible Control mode
Silent mode allows the oven control to operate without audible
tones. The control may be programmed for silent operation and
later reset to operate with all the normal audible tones.
To set for silent or audible mode:
1. Press and hold Delay Start for 6 seconds.
2. Press Self Clean to toggle between bEEP On or bEEP OFF.
(Figure 7)
3. Press to accept choice.
Setting Oven Lockout
The control may be programmed to lock the oven door and lock
the oven control keys.
To activate the oven lockout features:
1. Be sure oven door is completely closed.
2. Press and hold for 3 seconds. (Figure 8) door Loc will
appear in the display. The motor driven door latch
mechanism will begin locking the oven door automatically.
Do not open the oven door. Allow about 15 seconds for the
oven door to completely lock. Once door is locked, Loc will
appear in the display.
To cancel the oven lockout feature:
1. Press and hold for 3 seconds. The motor door latch
will begin unlocking the oven door automatically. Do not
open the oven door. Allow about 15 seconds for the oven
door to completely unlock.
2. When the Loc message no longer displays, the oven door
may be opened and the oven control keypad will be
available for use.
Important note:
• To avoid damage to the oven door latching mechanism, do
not attempt to open or close the oven door whenever the
door Loc message is displayed.
• If a control key is pressed when oven lockout is active, the
control will triple beep indicating the key action is not
available when the oven lockout feature is active.
Operating Oven Lights
The interior oven lights will automatically turn on when the oven
door is opened.
Press to turn the interior oven lights on and off whenever
the oven door is closed.
The interior oven lights are located on the rear wall of the oven
interior and are covered with a glass shield. The glass shield
protects the bulb from high temperatures and should always be
in place whenever the oven is in use.
To replace the interior oven light, see “Replacing the oven light”
on page 23.
Figure 6: Display showing Fahrenheit and Celsius
Figure 7: Display showing audible and silent operation
Figure 8: Display showing door locking and in locked position
