27” Thermal and Thermal
Convection Double ovens
Before you start...
Read the electricaT and carpentry
instructions.
Proper installation is your responsibility. A
qualified technician should install this oven.
Make sure you have everything necessary for
correct installation. It is the responsibility of the
installer to comply with the installation
clearances specified on the serial/rating plate.
The serial/rating plate can be found behind the
oven door on the front frame of the oven.
Check location where the built-in oven will be
installed. The location should be away from
strong draft areas, such as windows, doors, and
strong heating vents. The built-in oven should
be located for convenient use in the kitchen.
Remove all packaging material from
microwave oven cavity. Check microwave oven
area for damage - see WARNING below. If
any damage is evident, do not operate until
microwave oven is checked by an authorized
service technician.
Cabinet opening dimensions that are shown
must be used. Given dimensions provide
minimum clearance. Contact surface must be
solid and level and flush with the bottom.
The recessed installation area must provide
complete enclosure around the recessed
portion of the oven.
ALL OPENINGS IN THE WALL OR FLOOR
WHERE THE BUILT-IN OVEN IS TO BE
INSTALLED MUST BE SEALED.
Electrical ground is required. See “Electrical
requirements.”
Cabinet door
P
‘Note: There must be 1”
min. between bottom of
cabinet door and top of
oven console.
Oven control
4-112” exoosed
trim, do&r and
27” min.
cabinet width
I L
e4-L
\
\
Do Not’,
seal oven \
to cabinet. ’
\
24” min. overal
cabinet depth
idle depth
/2” without
die\.
I
i
opening
49”
I
depth
cabinet I
7
49-7/w -
overall
height
See Note:
opening
height
i
I
I
I
I
I
I Electrical
supply junction
1 box
46-13/16”-
ret :es
hl eic
;sed
Iht
nin.
1
1
H
11” min.
I
NOTE:
I
I
The oven support surface must be flush
with the bottom of the cabinet cutout.
I
ordinances.
overall width
\Thermal - 23k6”
Thermal
convection -
h
Cabinet Damage
Do Not block the oven vent.
Blocking the oven vent may cause cabinet
damage and poor baking performance.
Excessive Microwave Energy Exposure
l Do Not attempt to operate the microwave
oven with the door open.
l Do Not tamper with or defeat the safety
interlocks.
l Do Not place objects between the
microwave oven front face and door.
l Do Not allow soil or cleaner residue to
accumulate on sealing surface of the
microwave oven door.
. Do Not operate the microwave oven if
damaged.
l Do Not operate the microwave oven if:
- door is bent.
- hinges and latches are broken or
loose.
- door seals, sealing surfaces or
glass are broken.
The microwave oven door must close
properly to provide safe operation.
b Only have a qualified repair person
adjust, repair and check microwave oven
for microwave leakage after a repair is
made.
b Do Not use microwave for commercial
purposes. The microwave oven in this
unit is designed for household use only.
Failure to follow these instructions could
result in exposure to excessive microwave
5nerav.
Tools needed for
installation:
If codes permit and a separate grounding
wire is used, it is recommended that a
qualified electrician determine that the
grounding path is adequate.
IMPORTANT:
Save Installation Instructions for the local
electrical inspector’s use.
screwdriver
IA
This appliance must be connected to
. the proper electrical voltage and
frequency as specified on the serial/rating plate
located behind the oven door on the front frame.
Models rated at 7.0 kw on 240 volts (5.3 kw on
208 volts) or more require a separate
40-ampere circuit. Models rated at 3.6 kw on
240 volts (2.7 kw on 208 volts) or less require a
separate 30-ampere circuit. Fuse both sides of
the line. A time-delay fuse or circuit breaker is
recommended.
‘arts supplied
‘or installation:
Electrical
requirements
(BJ
OVEN MUST BE CONNECTED WITH
. COPPER WIRE ONLY.
ICI
Wire sizes and connections must
. conform to the reauirements of the
National Electrical Code, ANSI/NFPA 70 -
latest edition**,
and all local codes and
ordinances. Wires sizes and connections must
conform with the rating of the appliance.
Copies of the standards listed may be obtained
from:
**National Fire Protection Association
Battetymarch Park
Quincy, Massachusetts 02269
Electrical Shock Hazard
l Electrical ground is required on this
appliance.
l Do Not ground to a gas pipe.
l Do Not have a fuse in the neutral or
grounding circuit. A fuse in the neutral or
grounding circuit could result in an
electrical shock.
l Check with a qualified electrician if you
are in doubt as to whether the appliance
is properly grounded.
Failure to follow these in instructions
could result in serious injury or death.
Electrical Shock Hazard
It is the customer’s responsibility:
l To contact a qualified electrical installer.
l To assure that the electrical installation is
adequate and in conformance with
National Electrical Code, ANSUNFPA 70 -
latest edition**,
and all local codes and
ordinances.
Failure to do so could result in fire,
electrical shock or other personal injury.
Personal Injury Hazard
Securely fasten oven to cabinet using the
screws provided.
Failure to do so could cause the oven to
move or tip during use and result in
personal injury.
_ -
Panel A
