Low Profile – 1600-000-A Advantage Series Service Manual – Domestic
18
PARTS / GENERAL - 1600-000-A ADVANTAGE SERIES
LETTER PART # DESCRIPTION
A 369110 Access Window Assy
B 369929 Window Retainer
C 369926 Window Frame, Bottom
D 369925 Glass, Access Window
E 369927 Window Frame, Top
F 369930 Screw, 10-32x1/4
G 369211 Thumb Screw
H 369058 Baffle
I 370253 Drive Cover L.H.
J 1609 Oven Top
K 370252 Drive Cover L.H.
L 369745 Hinge Assy., Right
M 369723 Door Assy., Small
N 369783 Latch, Spring
O 369717 Finger Retaining Bracket
P 369057 Screw, Finger Retaining Bracket
Q 369501 Latch
R 369238 Leg
S 369030 Caster, High Stand
369390 Caster, Low Stand
T 370167 Baffle, Air Return U.L. L.R. (S/N 35950 and below)
370663** Baffle, Air Return U.L. (S/N 35951 and above)
U 370166 Baffle, Air Return U.R. L.L. (S/N 35950 and below)
370662** Baffle, Air Return U.R. (S/N 35951 and above)
V 370168 Finger Housing T-1, T-3, B-2, B-4 (S/N 35950 and below)
370665*** Finger Housing T-1, T-3, B-2, B-4 (S/N 35951 and above)
370169 Finger Housing T-2, T-4, B-1, B-3 (S/N 35950 and below)
370664*** Finger Housing T-2, T-4, B-1, B-3 (S/N 35951 and above)
W Columnating Plates—See Installation Operations Manual
X 369707 Finger Cover
Y 369740 Handle Assy.
Z 369718 Door Assy., Large
AA 369931 Screw, 8-32x3/8
BB 369746 Hinge Assy. Left
** Units from S/N 35951 and above DO NOT contain lower Air Return Baffles. These units only contain a
total of two (2) Air Return Baffles which are placed above the top finger assemblies.
*** These parts have minor design changes not shown in the exploded view drawing on page 19.
