16011105/R3
STABILITY BRACKET
To reduce the risk of the appliance tipping due to improper use or door loading, it must be securely
installed using the stability bracket supplied.
1. Place the stability bracket on the floor as shown in figure 2.
If there is no side wall, the dimension given as 0.5 cm will be the distance of the left / right side of
the appliance to left / right of the stability bracket. If there is a side wall, the dimension given as
2.5 cm will be the distance of the left / right side of the stability bracket to the side wall.
If your appliance is 50 cm wide, the distance between the back wall and the top edge plate
should be zero.
2. Mark the locations of the 2 holes of the stability bracket on the floor.
3. Use a 7.5 mm masonry drill bit to make the holes and insert the plastic anchor.
4. Secure the bracket to the floor using the screws supplied.
5. Slide the appliance into place (Figure 1).
