4
Espresso operation
Filling the water reservoir
1 Remove to fill the water reservoir, A
slide the water tank upwards using the
handle. Open the lid of the water
reservoir Î by pulling up and sliding
backwards.
IMPORTANT: Do not overfill or carry with
the handle when full.
2 Fill the water reservoir Î using cold tap
water, 1.7 litres maximum. B
3 Replace the water reservoir by sliding it
back into place. C
Using with ground coffee
Ensure the coffee/steam lever Ì is in
the off position.
1 Plug the unit into the power outlet.
2 Switch the unit on by pressing the on/off
switch ›. The blue 'power light' ¤ and
the display Í will illuminate.
3 Pre-heat your coffee cups by placing
them upside down on the warming
plate ⁄.
Note: This machine is designed for use
with espresso or cappuccino cups only. The
coffee will emerge much weaker if larger
cups are used.
4 Select the required filter „ for 1 cup or
‰ for 2 cups and place in the filter
holder ‡. D
Note: The 1 and 2 cup filters have many
inlet holes and a single outlet hole.
5 Using your measuring spoon Â
supplied, place one or two measures of
ground coffee into the filter, depending
on filter choice. With the other end of the
measuring spoon, use the compactor Ê
to tamp down the coffee. E
IMPORTANT: Be sure not to overfill the
filter with too much coffee, and wipe around
the edge of the filter to remove any coffee
grounds.
6 Place the filter holder ‡ on the brewing
head fi and position the handle so it
points to the left. F
• Ensure the filter holder is flat against the
brewing head and turn the handle
towards the right G as far as it will go.
7 Place 1 or 2 pre-heated cups below the
holes in the filter holder H and I. When
the coffee maker is at the correct
temperature the sign will be
displayed.
8 Move the lever down to the coffee
setting. You will hear the machine make
a pumping noise, this is normal.
9 Once the cups are filled to the desired
level, pull the lever to the off position.
Water will still filter through for
approximately 8 seconds after the
machine has been turned off.
10Carefully remove the filter holder by
turning the handle slowly to the left.
AB
CD
EF
GH
