Top Products
Installation Tools
• tin snips • large zip ties
• assorted screw drivers • fabric flexible duct
• electric drill - class II rated
• hammer • mastic tape
• wire strippers • alum. foil duct tape
• knife • zip ties
• caulking gun • 1/2” I.D. drain hose
• smoke pencil
Balancing Tools
• Pitot Tube Balancing Kit
[Case, 8 ft. vinyl tubing, Pitot tube,
magnehelic gauge (0 - 0.25”), and
mounting plate]
•
Pitot Tube with instructions
and Digital Manometer (with resolution of
0 - 0.25” - must read to 1/100ths of an inch)
Heat Recovery Ventilators (HRV) are designed to provide
fresh air while exhausting an equal amount of stale air.
The HRV is equipped with an aluminum core. The device
uses the stale air that is being exhausted to condition the
fresh air as it is being brought in.
These instructions are intended as a general guide and do
not supersede local codes in any way. Consult authorities
who have jurisdiction before installation.
Required Tools................................................................1
Application.......................................................................1
General ...........................................................................1
Table of Contents............................................................1
Engineering Data ............................................................2
Motorized Damper Assembly..........................................3
Clearances & Requirements ...........................................4
Installation....................................................................4-6
Electrical .........................................................................7
Dehumidistat Operation ..................................................8
Air Flow Balancing .....................................................9-10
Maintenance .................................................................11
INSTALLATION INSTRUCTION FOR FRESH AIR EXCHANGER
Application
General
Table of Contents
Required Tools
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TI-FAE-001
1207
MODELS 94-EXCHANGER, 94-EXCHANGER-MD, 99-MD-KIT
See page 3 for 99-MD-KIT installation instructions
ATTENTION
