16_ Surface cooking
LOCATION OF THE INDUCTION COOKTOP ELEMENTS AND
CONTROLS
2
4
1
5
3
6 inch
6 inch
11 inch
7 inch
1. Induction Left Front Cooking zone 2400W; with Power Boost 3700W (11 inches/ 280 mm)
2. Induction Left Rear Cooking zone 1400W; with Power Boost 2000W (6 inches/ 160 mm)
3. Induction Right Front Cooking zone 1400W; with Power Boost 2000W (6 inches/ 160 mm)
4. Induction Right Rear Cooking zone 1800W; with Power Boost 2600W (7 inches/ 180 mm)
5. Touch Control
Safety instructions. Residual heat
The Induction cooktop has a residual heat indicator for each hotplate. It •
shows which hotplates are still hot. You should, therefore, avoid touching the
hotplate when this indicator is shown.
Although the Induction cooktop is switched off, the indicator • will stay lit
while the hotplate is still hot.
if the pan has been removed but the hotplate has not been swiched off, the •
indicator
will flash, showing the power level selected.
COOKWARE FOR INDUCTION COOKING ZONES
The Induction Cooktop can only be turned on when cookware with a magnetic base is placed on
one of the cooking zones. You can use the following suitable cookware.
