Your Microwave Oven and Its Components
Turntable
Grill Element
Oven AirVent
Control
Panel
Turntable Rotor
Turntable
Support Ring
ViewingWindow
Door Locking
Assembly
Grilling Plate*
*Safety Handle not illustrated
Ventilation Slots
Introduction
Unpackingthe MicrowaveOven
Please make sure you read all the instructions and the safety
notescarefullyandthatyoufamiliariseyourselfwiththefeatures
andoperationofyourovenbeforeuse.
Removethepolystyrenetoppackingpiecesandliftouttheoven.
Unpacktheovencompletelyremovingalltheprotectivetape.
Open the oven door. In the oven compartment you should find
the turntable and rotating support ring, the metal non-stick
grillingplateandasafetyhandle.Unpackalltheseitems.
Check the oven carefully, especially the door,door seals and the
lockingmechanism.Ifanyitemsaremissingordamaged,contact
yournearestTescostoreforassistance.
If possibleretainthe packaging.Ifyoudispose ofthe packaging,
dosohavingregardtorecyclingprovisionsinyourarea.
Preliminaries
Place your microwave oven on a flat, level stable work surface
awayfromsourcesofcold,heatanddamp.
For
$
$
$
$
$
goodventilation,therearoftheovenshouldhaveaclearance
of at least 10 cm from the wall, the free distance above the top
shouldbeatleast20cmandthereshouldbeagapofatleast5cm
atbothsides.
Theovenshouldbepluggeddirectlyintothewallsocketandnot
viaanadaptororanyotherpowersharingdevice.
Opentheovendoor.
Check thatthe rotor ison themotor drivespindle. Ifnot, you
will need to attach it. There is a flat
machined on the motor spindle to
holdthe rotor securewhilethe oven
is operating. Rotate the rotor
slightly back and forth until it drops
securelyintoplaceoverthespindle.
PlacetheTurntableSupportRingintheoven
Lower the turntable onto the Rotor. There is a recess in the
turntabletolocksecurelyontherotor.
You must always operate your microwave oven with the
turntableassemblyproperlyinplace.
InstallingtheTurntable
5cm
20cm
5cm
10cm
Page 4
START
/
QUICKS TART
/
POWER
CONVECTION
GRILL/
MICRO+GRILL
MICRO+
CONVECTION
WEIGHT/CLOCK
TIME
MENU
STOP/CANCEL
The grilling plate
should be used for
grilling only.
Do not use for any
process involving
convection or
microwave cooking.
