INSTALLATION MANUAL FOR
TCGD DISPLAY CASES (DRY BAKERY) MODELS
CURVED GLASS DISPLAY CASES
- DRY BAKERY -
CONGRATULATIONS!
You have just purchased the finest display case
available. You can expect many years of
trouble-free operation.
TCGD-77
TCGD-50
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
(636)-240-2400 • FAX (636)272-2408 • INT’L FAX (636)272-7546 • (800)325-6152
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471
TABLE OF CONTENTS
Safety Information
Safety Precautions ––––––––––––––––––––––– 1
Proper Disposal –––––––––––––––––––––––––– 2
Connecting Electricity ––––––––––––––––––––– 3
Adapter Plugs ––––––––––––––––––––––––––– 3
Installation / Operation Instructions
Ownership –––––––––––––––––––––––––––––– 4
Required Tools ––––––––––––––––––––––––––– 4
Uncrating ––––––––––––––––––––––––––––––– 4
Locating –––––––––––––––––––––––––––––––– 5
Leveling Cabinet ––––––––––––––––––––––––– 5
Electrical Instructions ––––––––––––––––––––– 6
Start-up –––––––––––––––––––––––––––––––– 6
Wire Gauge Chart –––––––––––––––––––––––– 7
Shelving Installation –––––––––––––––––––––– 8
Installing Optional Castors ––––––––––––––––– 9
Installing Optional Formica Kit ––––––––––––– 10
Maintenance, Care & Cleaning
Optional Sealing Cabinet To Floor –––––––––– 11
Cabinet Cleaning –––––––––––––––––––––––– 11
Light Bulb Replacement ––––––––––––––––––– 12
Warranty (U.S.A. and Canada ONLY!) ––––––– 13
4/6/06 1K SB #912625
* Spanish, German, and French versions included.
