6-10 CHAPTER 6: MONITORING THE SWITCH 2000 TR
LCD Status
The LCD console located on the front panel of the
Switch 2000 TR provides useful hardware, software,
and system version information. Refer to Chapter 5
for more information.
Figure 6-9 LCD Console Status Chart
To view the LCD status, take these steps from the
Switch 2000 TR>Unit Id banner:
1 Press [Down Arrow] until Switch 2000 TR>Status>
appears.
2 Press [Enter].
STATUS>HW Version appears.
3 Press [Enter].
HW Version#: appears and displays the hardware ver-
sion of the Switch 2000 TR.
4 Press [Left Arrow] to return to the STATUS >HW Ver-
sion> display.
5 Press [Down Arrow].
STATUS >SW Version> appears.
6 Press [Enter].
SW Version #> appears and displays the Boot software
version stored on the Switch 2000 TR.
7 Press [Left Arrow] to return to STATUS > SW Version>.
8 Press [Down Arrow].
STATUS >BOOT SW Ver> appears.
9 Press [Enter].
Boot SW Ver #: displays the software version stored in the
EPROM of the Switch 2000 TR. This version number is
automatically updated when you download new software.
10 Use [Left Arrow] to scroll back up through the menus.
[Enter]
[Enter]
[Left Arrow]
[Down Arrow]
[Enter]
[Left Arrow]
[Down Arrow]
[Enter]
[Left Arrow]
> Status
Switch 2000 TR
> Status
Switch 2000 TR
STATUS
>HW Version >
STATUS
>HW Version >
STATUS
>Boot SW Ver >
HW Version #:
[R/O Version]
SW Version #:
[R/O Version]
Boot SW Ver #:
[R/O Version]
