Cisco TelePresence System 3200
OL-14521-01
Chapter 4 Building the Lighting Assembly
Parts List
Step 22 Attach the left and right corner Reflector Transition pieces to the Reflector tops.
Figure 4-22 Left and Right corner Reflector Transition pieces
Note Tighten all screws from Figure 4-18 through Figure 4-22. The goal is to ensure the reflector pieces form
a “seamless hood” around the lighting assembly.
22
18
18
22
201145
28
27
