CHAPTER
6-1
Cisco TelePresence System 3200
OL-14521-01
6
Building the First Row Table Assembly
Revised: July 28, 2008, OL-14521-01
Parts List
Key Part Description Part Number Qty Ctn Notes
1
Tabletop leg base 800-28454-xx
800-28628-xx (left)
3
1
52-
54
52
2
Metal packaging brace 700-24275-xx 4 41-
43,
57
3
Molded foam bumper 800-28625-xx 4 41-
43,
57
4
Tabletop section: right wing 95-9690-xx
Kit # 74-5302-xx
1 58
5
Tabletop section: Center right 95-9687-xx
Kit # 74-5300-xx
1 58
6
Tabletop section: center 95-9686-xx
Kit # 74-5299-xx
1 58
7
Tabletop section: Center left 95-9689-xx
Kit # 74-5301-xx
1 58
8
Tabletop section: left door 95-9691-xx
Kit # 74-5303-xx
1 58
9
Connecting plate 700-27292-xx 6 50
10
Draw bolt No part number 12 1
11
Left tabletop hinge 51-4539-xx 1 1
12
Spline No part number 5 1
13
“Please close” label 56-15736-xx 1
14
M8 x 16 mm screws, black 48-2430-xx 30 1
