4 1 • Installation
Setting Up the Projector
1. Place the projector on a sturdy, level surface within five feet of the computer
or video source.
Caution: Do not hold the projector by the lens when you move it. This
will damage the lens.
2. Place the projector the proper distance from the screen.
The distance between the projector and the screen determines the actual
image size. Use the following general guidelines to determine the proper
distance.
Image size Distance from screen
(diagonal) (approximate)
Maximum Zoom Minimum Zoom
300 inches (25 feet) 214 inches (30 feet) 40 feet
204 inches 146 inches 27 feet
96 inches 69 inches 13 feet
60 inches 42 inches 8 feet
30 inches 21 inches 4 feet
3. Turn the projector so the lens is at a right angle to the screen. If the projector
is not at a right angle, the screen image will be crooked.
