80 A • Technical Specifications
Monitor and VGA connector pin assignments
The Monitor connector is a female video RGB, 15-pin micro-D style connector, and
the VGA connector is a male video RGB, 15-pin micro-D style connector. The pin
assignments for both connectors are as follows:
Input pin Signal
1 Red analog input
2 Green analog input with composite sync
3 Blue analog input
4 GND
5 GND
6 Red GND
7 Green GND
8 Blue GND
9NC
10 Sync GND
11 GND
12 NC
13 Horizontal sync/composite sync input
14 Vertical sync input
15 NC
