Pin Assignments
The following tables describe the pin assignments for the three connectors of the
Y-cable: LCD connector, VGA connector, and Monitor connector. The pin assign-
ments for the VGA and Monitor connectors are identical.
LCD connector pin assignments
The LCD connector is a 26-pin D-style connector. Its pin assignments are as
follows:
Input pin Signal Output pin
1 Vertical sync 10
2 Horizontal sync 11
8 Blue analog 14
6 Intensity digital 12
7 Green digital 13
9 Red analog 15
16 Blue digital 3
17 Red digital 4
18 Green analog input with composite sync 5
20 GND
21 GND
22 GND
23 Digital/analog video cable ID
24 GND
25 VGA/no video cable ID pin
26 Monochrome digital (Hercules) 19
