MIX 301 • Reference Information
MIX 301 • Reference Information
Reference Information, cont’d
11
Parts List
Included parts
Included Part number
parts to reorder
MIX 301 60-737-01
Power supply: universal 12 VDC, 1.0 A 70-055-01
3.5 mm captive screw connectors, 3-pole (x4) 10-319-13
3.5 mm captive screw connector, 2-pole
Tweeker (small screwdriver)
Rubber feet (unattached)
User’s manual
Optional Accessories
Accessories Part numbers
VersaTools back of the rack mounting kit 70-367-01
1U 19" VersaTools rack shelf kit 60-190-20
Basic VersaTools rack shelf 60-604-20
1U 19" rack shelf kit 60-190-01
1U basic rack shelf kit 60-604-01
Under desk mounting kit 70-212-01
Projector mounting kit 70-217-01
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount .................................. Yes, with optional 1U rack shelf, part
#60-190-01 or 60-604-01; or VersaTools
®
rack shelf, part #60-190-20 or 60-604-20; or
the Back of the Rack Mounting Kit
#70-367-01.
Also furniture mountable with Under-
desk Mounting Kit, part #70-212-01, or
attachable to a projector mount with
optional mounting kit #70-217-01.
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.7" H x 2.2" W x 3.0" D (1U high, one-
eighth rack wide)
4.3 cm H x 5.6 cm W x 7.6 cm D
(Depth excludes connectors.)
Product weight ............................. 0.2 lbs (0.1 kg)
Shipping weight ........................... 2 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
