MPX 423 A • SIS Programming and Control
PRELIMINARY
Command ASCII Command
(host to switcher)
Response
(switcher to host)
Additional description
Query Firmware Version
Read controller
firmware version
Q/q
X1(]
Query verbose version
information
0Q
X1(X2)X2)]
Provide a detailed status of the
Ethernet protocol firmware, the
controller firmware, and any
firmware upgrade.
The firmware that is running is
marked by an asterisk (*).
A caret (^) indicates that the
firmware has a bad checksum
or an invalid load.
?.?? indicates the firmware is
not loaded.
N
Response description:
Controller firmware version - update firmware version
]
Request System Status
Read system status S
X2@]
System Reset (Factory Default)
E
ZXXX
}
Zpx
]
Clears all ties, resets all audio
gains to 0 dB, and resets volume
to 100%.
Absoluete System Reset
E
ZQQQ
}
Zpq
]
Similar to system reset (ZXXX).
Resets IP address and subnet
mask to defaults of:
IP address = 192.168.254.254
subnet mask = 255.255.0.0
IP Setup Commands
Set matrix name
(location)
EX2%
CN
}
Ipn
•X2%] X2%
= Matrix name (24
character max.)
Invalid characters:
+ ~ @ = ‘ [ ] { } < > : | \ ?
Set unit name to factory
default
24
E•
CN
}
Ipn•
X2(] X2(
= Default name:
combination of model-name
and last 3 pairs of MAC address
(e.g., MPX-423-A-00-02-3D)
Read matrix name
(location)
E
CN
} X2%] X2%
= Matrix name (24
character max.)
Invalid characters:
+ ~ @ = ‘ [ ] { } < > : | \ ?
Set time/date
EX3&
CT
}
Ipt
X3&] X3&
= GMT date:
(MM/DDD/YY•HH:MM:SS)
Read time/date
E
CT
} X2^] X2^
= GMT date:
[WWW,•DD•MMM•YYYY•
HH:MM:SS•GMT]
Set GMT, offset
EX3(
CZ
}
Ipt
X3(] X3(
= GMT offset (-12.0
through 14.0 hours and minutes
removed from GMT)
