Programming and Control, cont’d
MPX 423 A • SIS Programming and Control
4-10
PRELIMINARY
Command ASCII Command
(host to switcher)
Response
(switcher to host)
Additional description
Read GMT, offset
E
CZ
} X3(] X3(
= GMT offset (-12.0
through 14.0 hours and minutes
removed from GMT)
Set daylight saving
time
EX4)
CX
}
Ipt
X4)] X4)
= Daylight saving time
0 = Daylight saving time off/
ignore
1 = Daylight saving time
(northern hemisphere)
2 = Daylight saving time
(Europe)
3 = Daylight saving time
(Brazil)
Read daylight saving
time
E
CX
} X4)]
Configure parameters
24
EX!
*
X4&
,
X4*
,
X4(
,
X5)
CP
}
Cpnx1•Ccp,
X4&
,
X4*
,
X4(
,
X5)]
X4&
= Baud rate: (9600, 19200,
38400, 115200)
X4*
= Parity: Odd, Even, None,
Mark, Space
X4(
= Data bits: 7 or 8
X5)
= Stop bits: 1 or 2
Read port parameters
EX4^
CP
} X4&
,
X4*
,
X4(
,
X5)]
Set port mode
EX4^
*
X5!
CY Cpm
X4^•
Cty
X5!] X4^
= Port # XX. The port
number will be represented as
two ASCII characters (2 bytes)
(example: port 01 is represented
as 30 31 in hex)
X5!
= Port type: 0 = RS-232
Read port mode
EX4^
CY
} X5!]
Configure flow control
24
EX4^
*
X5@
,
X5#
CF
}
Cpn
X!•
Cfl
X5@
,
X5#] X4^
= Port # XX. The port
number will be represented as
two ASCII characters (2 bytes)
(example: port 01 is represented
as 30 31 in hex)
X5@
= Flow control: Hardware,
Software, None
X5#
= Data pacing (specified in
milliseconds between bytes):
0000 - 1000 (default = 0 ms)
View flow control
EX4^
CF
} X5@
,
X5#]
View receive timeout
EX4^
CE
} X1&
,
X1*] X1&
= 10s of milliseconds wait
time for characters coming into
a serial port before terminating
(default = 10 = 100ms, max =
32767
X1*
= 10s of milliseconds
wait time between characters
coming into a serial port before
terminating (default = 2 = 20ms,
max.= 32767)
Set DHCP on or off
EX4%
DH
}
Iph
X4%] X4%
= DHCP (0 = off; 1 = on)
Read DHCP status
E
DH
} X4%] X4%
= DHCP (0 = off; 1 = on)
Set IP address
EX2&
CI
}
Ipi
X2&] X2&
= IP address
(###.###.###.###)
Read IP address
E
CI
} X2&] X2&
= IP address
(###.###.###.###)
Read hardware (MAC)
E
CH
} X3$]
