Chapter 3 Basic Printer Operations
3-5
Optional feeder in Simplex Print
All media should be tested prior to purchase of the printer.
Duplex Print
1 Applicable only to optional paper tray capable of loading up to legal size media in Tray 1.
2 Custom paper size is only supported using the in built feeder, it is not supported in the op-
tional feeder.
All media should be tested prior to purchase of the printer.
Not Usable Print Media
Print Media which is not usable in the Intelliprint 8008N includes:
z Thick or thin sheet out of the specifications
z Media other than those for the laser printer
z Thermally sensitive paper or films, e.g., thin OHP films (transparencies)
z Processed media, e.g., perforated media or media with holes for a binder
z Media with staples, paperclip or tape attached to it
z Preprinted forms, printed media, and media printed by a copier (Using
media previously output from a printer or copier may cause jams or other
trouble.)
z Media that is creased, wrinkled, warped, blotched, or torn
z Moist or wet media
z Media left out for a long period after it has been taken out of their package
z Media with adhesive such as paste
Media type Media specifications Tray capacity Media size (W x L in mm)
Plain paper For laser printer.
Weight: 60 to 90 g/m
2
(16 to 24 lbs).
About 500 sheets A4 (210 x 297)
B5 (ISO) (176 x 250)
B5 (JIS) (182 x 257)
Letter (215.9 x 279.4)
Executive (184.2 x 266.7)
Thick paper For laser printer.
Weight: 90 to 105 g/m
2
(24 to 28 lbs).
Media type Media specifications Media size (W x L in mm)
Plain paper For laser printer.
Weight: 60 to 90 g/m
2
(16
to 24 lbs)
.
A4 (210 x 297)
B5 (ISO) (176 x 250)
B5 (JIS) (182 x 257)
Letter (215.9 x 279.4)
Executive (184.2 x 266.7)
Legal
1
(215.9 x 355.6)
Custom (100 to 215.9 x 210 to
297)
2
Thick paper For laser printer.
Weight: 90 to 105 g/m
2
(24 to 28 lbs)
.
