Adjusting Paper Path Alignment
Advanced Topics 6-15
Advanced Topics
Measuring Alignment
You will now read the adjustment values.
1. Carefully and accurately, fold the top part of the Simplex feed alignment ruler sheet,
shown in Figure 6-8.
Figure 6-8 Simplex Feed Alignment Ruler Sheet
Adjustment scale
Fold line
