Appendix A Specifications
Scanning device 2 x 850 cell, 108 mm Contact Image Sensor (CIS)
Light source Tri-color LED
Scanning method Concurrent, duplex (front and rear)
Document size Height: 56 to 106 mm (2.12 to 4.17 in.)
Length:
99 to 228 mm (3.91 to 8.97 in.)
Weight: 60 to 120 g/m
2
(16 to 32 lbs.)
Auto feeder capacity Depending on document thickness and condition: 1 to 50 documents
Output sort pockets Depending on document thickness and condition: 1 pocket / 50 documents
Scanning capture speed 50 cm/sec. (19.7 in./sec.) grayscale/bi-tonal/color
Scan system throughput Speed varies depending on scanner model, the scan mode and PC performance:
i6015: single feed
i6060: 65 dpm
i6090: 100 dpm
Scanner image format Uncompressed grayscale, bi-tonal and color
Grayscale image depth 8 bits/pixel (256 shades of gray)
1 bit/pixel bi-tonal (B&W)
4 bits/pixel (16 shades of gray)
software selectable from the API
Color image depth 24 bits/pixel (16,777,216 shades)
Image resolution 200 x 200 dots per inch (dpi)
100 x 100 or 200 x 100 software selectable from the API
Image formats Bitmap (bmp); 4-side cropping and image rotation performed by the API
Image compression TIFF Group 4 and JPEG
Image transmission Through the USB port
Double feed device Infra Red (IR) Transmissive type
Double feed detection Programmable delay (performs skip-over function)
Perforation skipping Included (selectable perforation size)
Interface USB 2 (backwards compatible to USB 1.1)
Operating system Windows 2000 and Windows XP
Minimum PC configuration 1 GHz Pentium III processor
128 MB RAM
100 MB free disk space
Windows 2000 or XP
CD-ROM drive
USB port 1.1
Recommended PC
configuration
2.4 GHz Pentium IV processor or greater
512MB RAM
200 MB free disk space
Windows 2000 or XP
CD-ROM drive
USB port 2.0
