INTRODUCTION AND SPECIFICATIONS
Specifications
4_03 OMH-6722B 3
CHAPTER 1
๎€“
Specifications
Input Specifications
Power Measurement
Range 100 nW ~ 1 W
2
; -40 dBm ~ + 30 dBm
2
Accuracy +3.5% (450 to 990 nm)
1,3,4
Wavelength Measurement
Range 400 to 1100 nm
2
Accuracy + 1.0 nm
3
Temperature coefficient < + 0.03 nm /
o
C
Linearity with power change < +
0.5 nm
(Maximum change in measured wavelength due to power change)
Sampling Rate
Slow 16 samples @ 60 ms / sample
Medium 4 samples @ 60 ms / sample
Fast 1 sample @ 60 ms / sample
Input Bandwidth
Slow 1 Hz
Medium 10 Hz
Fast 60 Hz
Analog Output Specifications
Analog output representing the power measurement is available at the rear panel of the multimeter.
Refer to the OMM-6810B Instruction Manual for details.
Display
Left Display (Power)
Units
Linear Power
Log Power
pW, nW, ยตW, mW, W,
โˆ†P
dBm, dB
Range
Linear Power
Log Power
0.000 nW to 999.999 W
-99.999 to 99.999 dBm / dB
Resolution (Slow Update Rate)
Linear Power
Log Power
0.001 pW
0.001 dB
Resolution (Medium / Fast Update Rate)
Linear Power
Log Power
0.01 pW
0.01 dB
