26 Pelco Manual C1402M-B (2/98)
Table C. SB2600 Hardware Exploded Assembly Parts List
Item No. Quantity Description Part Number
A4Spacer, 1/4" O.D. x 1/8" L, #6 clear SPA8500
B10Nut, hex 6-32 SS ZH6-32NUTSH
C2Screw, 8-32 x 3/8", hex hd, m/s, SS ZH8-32X.375HMSS
D2Spacer 1/4" hex x 1/2. L, 6-32 tapped SPA8423
E-Not Used -
F3Screw, 6-32 x 38" pan hd, phil, SS ZH6-32X.375SPP
G3Screw, 8-32 x 3/4" L flat hd, phil, SS ZH8-32X.750SFS
H6Screw, 6-32 x 3/8" flat hd, phil, SS ZH6-32X.375SFP
I2Screw, 8-32 x 1/2" flat hd, phil, SS ZH8-32X.500SFS
J5Screw, 8-32 x 3/8" flat hd, phil, SS ZH8-32X.375SFP
K8Screw, 2-56 x 7/16" flat hd, phil, SS ZH2-56X.437SPP
4 Screw, 2-56 x 7/16" flat hd, phil, SS (SL models only) ZH2-56X.437SPP
L40Screw, 6-32 x 3/8" pan hd, phil, black oxide ZH6-32X.375BPP
M3Washer, internal star #4, SS ZH4LWSIS
N 36 Washer, internal star #6, SS ZH6LWSIS
O 3Screw, 8-32 x 1/2" pan hd, phil, SS ZH8-32X.500SPP
P2Washer, split lock, 1/4", SS ZH1/4LWSSL
Q8Washer, internal star #8, SS ZH8LWSIS
R8Washer, flat #8, SS ZH188X435X60C
S 3Screw, 4-40 x 1/4" pan hd, phil, SS ZH4-40X.250SPP
T1Screw, 1/4-20 x 1/2", hex hd, SS ZH1/4-20X.500CH
U 1Washer, flat 3/16" spcl size pltd ZH260X562X65C
V 1Set screw, 8-32 x 1/4" knur, hex soc, blk ZH8-32X.250S
W 4Set screw, 8-32 x 3/16" knur, hex soc, blk ZH8-32X.187S
X1Screw, 10-32 x 1/2" flat hd, phil, ss ZH10-32X.500CFS
Y 8Screw, 8-32 x 1/2" hex soc, C/S, SS ZH8-32X.500CS
Z1Screw, 1/4-20 x 3/4" hex hd, C/S, SS ZH1/420X361X62N
AA 4 Washer, nylon ZH131X361X62N
