Amana ASD2328HEB Refrigerator User Manual



Ice Storage Bin
The Ice Storage Bin is located below the automatic
ice maker.
To Remove:
Raise ice maker arm to deactivate ice maker. Lift
front of bin and pull out to its full extension. Lift up
front of bin and remove.
To Install:
Slide bin into railing below ice maker until bin locks
into place. Drop ice maker arm to activate ice maker.
IMPORTANT: Ice bin must be locked in place for
proper ice dispensing. Turn auger driver behind bin
counterclockwise (as shown) to properly align ice bin
with auger driver.
13
Freezer Features
Shelves and Baskets
Fixed Freezer Shelf
To Remove Clip-mounted Shelves:
Lift shelf from wall mounting
clips and pull left side of shelf
out of wall mounting holes.
To Install Clip-mounted Shelves:
Place left side of shelf in mounting holes and press
down into wall mounting clips.
Shelves
Shelves can be removed to meet individual storage
needs.
To Remove Shelf:
Snap right side of shelf up from
cabinet railing and slide to right.
To Install Shelf:
Replace shelf in left side cabinet railing. Snap shelf
into right side cabinet railing.
Baskets and Drawers
Baskets and drawers (style may vary)
slide out for easy access of items in
back.
To Remove:
Pull out to its full extension. Lift up front of basket
and remove.
To Install:
Slide basket or drawer into cabinet railing. Lift up
front of basket or drawer, and slide to the back of
refrigerator.
