INSTALLATIONADJACENTTOKITCHEN

CABINETS

Thisrangemaybeinstalleddirectlyadjacentto

existingcountertophighcabinets(36"or91.5cm

fromthefloor).

Forthebestlook,theworktopshouldbelevel

withthecabinetcoun tertop.Thiscanbe

accomplishedbyraisingtheunitusingthe

adjustmentspindlesonthelegs.

ATTENTION:therangeCANNOT

beinstalled

directlyadjacenttokitchenwalls,tallcabinets,

tallappliances,orotherverticalsurfacesabove

36"(91.4cm)high.Theminimumsideclearance

insuchcasesis6"(15.2cm).

Wallcabinetswithminimumsideclearancemust

beinstalled18"(45.7cm)abovethecountertop

withcountertopheightbetween

35½”(90.2cm)

and37¼”(94.6cm).Themaximumdepthofwall

cabinetsabovetherangeshallbe13"(33.0cm)



















EXHAUSTHOODINSTALLATION

Thisrangewillbestperformwhenusedwith PRO

lineBertazzoniexhausthoods.Thesehoodshave

been designed to work in conjunction with the

Bertazzoni range and have the same finishfor a

perfectlook.

For maximum performance, the height of the

bottomofthehoodfromtheworktopshouldbe



between 25 1/2" (65 cm) and 31 1/2" (80 cm).

This would typically result in the bottom of the

hoodbeing611/2"(156.2cm)to671/2"(171.5

cm) above the floor. These measurements

provide for safe and efficient operation of the

hood.

Before installation of the exhaust hood,

consult

local or regional building and installation codes

foradditionalspecificclearancerequirements.

Refer to the range hood installation instructions

provided by the manufacturer for additional

information.









A 36” (91,5 cm)

B 36” (91,5 cm)

C 13” (33,0 cm)

D 18” (45,7 cm)

E 35”1/2(90,2 cm) / 37” ¼ (94,6 cm)

F 6” (15,2 cm)
