STEP5:VISUALCHECKS

Beforereinstallingthebottompanel,the

followingvisualcheckmustbeperformedto

ensurethattheconversionhasbeencarriedout

properlyandwithoutdamagetoother

componentsoftherange.



A) CONNECTIONOFTHERMOCOUPLESTO

THERMOSTAT

Thethermocouplesforbothbroilerandmain

ovenburner

areconnectedtothesamemagnet.

Tightgentlythetwoconnectionsalternating

actiononthetwonuts.Donotfullytightenone

thermocouplebeforehavingstartedtotighten

thesecondone.





B) OVENIGNITERANDTHERMOCOUPLE

POSITION

Theappropriategapbetweenthetipofthespark

plugorthermocoupleandtheburnershallbe

approximately1/8’’.





Thetipofthesparkplugorthermocouplemust

fullyoverlapatleastthefirstgasemissionholeof

theburner.





Afterperformingallthesevisualchecks,reinstall

thebottompaneloftheovencompartmentand

proceedtosettingtheminimumforeach

burner.
