CONVEYOR COMPONENTS-SINGLE BELT UNITS
CLOSE-UP VIEWS
Ref. Part
No. No. Description
1 M10513 Pulley, Sprocket
M10572 Belt, for pulley 16"
2 M0108 Sprocket, 3/4 Bore, 10 per unit, 5 per conveyor assy
3 M2013 Shaft, Conveyor Drive Side
3a M2014 Shaft, Conveyor Idle Side
4 M2388 Belt Tensioner Assy
5 M5071 Crumb Pan, Remote, Idle for Single or Bottom Units
5a M6996 Crumb Pan, Remote, Idle for Top or Middle Units
6 M5335 Crumb Pan, Remote, Drive for Single or Bottom Units
6a M6995 Crumb Pan, Remote, Drive for Top or Middle Units
M10581 Crumb Pan, Integral, Drive for Top or Middle Units
M10570 Crumb Pan, Integral, Idle for Top or Middle Units
7 M10515 Conveyor Assy, Drive Side
8 M5066 Conveyor Assy, Idle Side
M4309
Product Stop
9
10
M2740
Belt,
Conveyor
(sold per foot,
total 11 feet)
5
M5071 Crumb Pan, Idle
for Single or Bottom Unit
6a
M6995
Crumb Pan, Drive
for Top or Middle Unit
4
M2388
Belt Tensioner Assy,
contains spring,
sleeve and shaft
M5066, Conveyor Assy, Idle
8
M10515,
Conveyor Assy, Drive
7
4
M2388
Belt Tensioner Assy,
contains spring,
sleeve and shaft
NOTE: Cut here to create a
masterlink. Call Tech. Service for
additional information.
1-800-331-5842
4
M2388
Belt Tensioner Assy,
contains spring,
sleeve and shaft
M2740
Belt,
Conveyor
(sold per foot,
total 11 feet)
10
2
M0108
Sprocket 3/4 Bore
Qty 5
3
M2013
Shaft, Conveyor,
Drive
1
M10513
Pulley, Sprocket
Depicts a blown-up section of belt,
M2740
10
2
M0108
Sprocket 3/4 Bore
Qty 5
2
M0108
Sprocket 3/4 Bore
Qty 5
3a
M2014
Shaft,
Conveyor Idle
M0122
Bearing,
Rulon
11
M10509
Retractable
Locking Pin
12
AUGUST 29, 2001 12 SG2136E & G
M6996 Crumb Pan, Idle
for Top or Middle Unit
5a
M5335
Crumb Pan, Drive
for Single or Bottom Unit
6
Ref. Part
No. No. Description
9 M4309 Product Stop
10 M2740 Belt, Wire S/S for Conveyor Assy 21" wide
Sold per foot, total 11 feet
11 M0122 Bearing, Rulon, 4 per unit, 2 per conveyor
assy
12 M10509 Retractable Locking Pin, for conveyor shaft
