11
REVERSING THE DOORS
We recommend that you reverse doors
before switching on for the first time.
Tools required: Small and medium size
flat and cross-headed screwdrivers, a
pair of pliers.
Spare Parts supplied in the plastic
bag: The following parts, which are
exclusively for left hand side fitted
hinge operation are supplied in a
plastic bag with the appliance:
- Door top trim hinge covers – there
are 2 different parts, one for each side
of top trim..
We suggest you keep all the parts
supplied in the plastic bag and also
parts, which have been removed when
reversing doors, in a safe place for
possible future, re-use.
IMPORTANT: We suggest you ask
somebody to help you when moving
the appliance around and to hold
doors when removing / re-fitting
hinges and doors to avoid any injury
and damage to the product.
Please refer to diagrams supplied. To
follow numbers in brackets below,
refer to the main diagram.
1. Switch off the appliance at the
socket outlet and pull out the mains
plug.
2. Remove all loose items and fittings
and food inside the appliance.
3. Gently prise off plastic hinge covers
on both sides of front top panel using
a small flat-headed screwdriver. (1-2)
4. Unscrew the bolts of the top hinge
and remove top hinge. (3)
5. Remove door carefully off the
bottom hinge and stand door upright
in a safe place.(4)
6. Gently prise off plastic hinge cover
on door top trim. Fit the other door top
trim plastic off hinge cover supplied in
the plastic bag.(5)
7. Gently tilt the appliance back
against a strong wall on its rear side
sufficiently to allow the lower hinge
to be removed. Take care to protect
the appliance, your wall and floor
coverings. You can utilise the original
packaging to do this.Once you tilt the
appliance back, check to make sure
the appliance is completely stable and
safe before you carry on. (6)
8.Unscrew and remove the front feet
and 1 bolt. (7)
9. Unscrew and remove the bottom
hinge. (8)
10. Unscrew and remove the bottom
hinge door stopper and bushing and
reposition them on the other side while
rotating the bushing 180°. (9)
11. Fit the bottom hinge and tighten
the screws as shown in figure. (10)
12. Fit the other front feet as shown in
figure. (11)
13. Rotate the top hinge 180°.
Unscrew the hinge pin and re-tighten it
to the opposite side. (12)
14. Fit the top hinge on the left hand
side bushing of the door. (13)
15. Locate and re-fit door to bottom
hinge pin. (14)
