2. Place the oil reservoir in the Side Fryer.
Locate the thermometer bracket on the right
side (Fig. 10).
4. Place the thermometer in the holder (Fig. 12).
7. Open the door to reveal the Quick Coupler in
the upper corner. Retract the Collar on the
Quick Coupler before attaching to the male
fitting (Fig. 8). Release the collar to lock the
connection.
3. Fill the oil reservoir with 2.67 qts (2.53 liters)
maximum of cooking oil, indicated by the marks
on the oil reservoir (Fig. 11).
Fryer Assembly (cont.)
English-6
Setup
Fig. 8
Fig. 10
1. Slide the grease tray into the rails below the
fryer (Fig. 9).
Fig. 9
Thermometer Bracket
Fig. 11
Max Fill Line
Fig. 12
8. Check that the hose has no kinks or sharp
bends and clears areas that will become hot
during use. Never put strain on the hose where
it joins a fitting.
6. Push the fuel hose connection through the
opening in the side grill panel (Fig. 7).
Fig. 7
DANGER
DO NOT FILL PAST MAXIMUM FILL LINE
MARKED ON THE OIL RESERVOIR or an oil
overflow may occur resulting in a fire which
could cause property damage, personal injury
or death.
