Loading the dishwasher
Using the cutlery basket
The cutlery basket can be split into three sections and its grid inserts may also be removed. The
smaller cutlery basket sections also fit in the upper basket (as shown in Fig. 21). Place long items
such as ladles, cooking spoons etc. on the cup racks of the lower or upper basket.
To split the cutlery basket (Fig.9)
1
Turn the locking lug(s) at the base of the handle to the side, as shown.
2
Lift the smaller section(s) to release the gripping hooks (the two upper ones are on the main
section and the two lower ones are on the smaller sections).
To reassemble the cutlery basket
1
Ensure that the locking lugs are turned to the side.
2
Lower the section(s) into place and make sure that all four gripping hooks reengage.
Using the grid inserts
The grid inserts prevent cutlery from nesting together.
For larger items (e.g. wire whisks), the grid insert may be removed.
To remove and replace the grid inserts (Fig.11)
To remove the grid insert of the smaller sections, put your fingers through their two biggest
holes and gently press on the plastic grid towards yourself. This will release the gripping hooks.
To remove the grid insert of the main section, locate the four gripping hooks on the grid insert
and gently pull the plastic at the hooks upwards to release them.
To replace the grid inserts, click them back into place, making sure that all gripping hooks
reengage into the appropriate hole in the side of the cutlery basket.
Fig. 8 Cutlery basket parts
Fig. 11 Removing the grid inserts
Fig. 10 Cutlery basket with grid
inserts in place
Fig. 9 Splitting the cutlery basket
1
2
Locking lug
Gripping
hooks
