Anti-Tip Device HANDLING AND INSTALLATION INSTRUCTIONS
22
Installation and User Guide CornuFé 1908 - 36" - USA / Can
08NOTINSTALFE8/USA-1
3. Drill a 3.5 mm diameter hole in the timber floor and
screw the stud directly into the floor.
4. Where the floor consists of tiles, concrete or another
hard material, drill a 10 mm diameter hole, push in the plug
and screw the stud into it.
5. Using the hex head screw and the No. 10 open-end
spanner, fasten the chain to the frame at the back of the
range. Make sure to properly secure the chain between the
frame and the washer.
6. Push the range into its position. The chain must hang
over the stud.
7. Remove the drawer at the bottom of the range by lifting
it slightly.
8. Reach the chain through the drawer opening in the
front.
