Form #SPC17-0902N Made in the U.S.A. © 2002 Berkel Company Litho in U.S.A.
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX 888-888-2838 • www.berkel.com
Tenderizer/Stir Fry Cutter Model 705
Model 705
Tenderizer/Stir Fry Cutter
Specifications
Models: ❑ Model 705 Tenderizer consists of 86
blades on two rollers providing 1,118 cutting
edges; design cuts and knits the meat from both
sides simultaneously for smooth meat flow and a
uniform tenderizing pattern that tightly seals in
juices when cooked.
❑ Model 705-S Stir Fry Cutter produces clean,
uniform strips of meat to a pre-set thickness of
1/2” (13 mm) or 3/8” (10 mm) thick. Stainless steel
knives cleanly cut up to 13 strips at a time.
❑ Model SFC Stir Fry Cutter Basket Assembly
converts 705 and earlier model Berkel tenderizers
to optional stir fry cutters.
Motor: 1-speed, 1/2 HP, totally enclosed, perma-
nently lubricated ball bearings, thermally protected.
Electrical: Furnished in 115/60/1, 7.6 amp, AC,
ETL listed.
Finish/construction: Finish is corrosion resistant
and sanitary burnished aluminum with clear Lexan
safety cover. The unit disassembles quickly
without tools for easy cleaning.
Transmission: Direct gear drive transmission,
resiliently coupled and enclosed with permanently
lubricated gearbox.
Cutting Capacity: Model 705 and 705-S handle
product up to 1-1/4” (32 mm) thick by 7-7/8”
(200 mm) wide.
Tenderizer Group: Model 705 Tenderizer Basket
assembly includes blades, rollers and strippers of
heavy-duty stainless steel with nylon spacers.
Stir Fry Cutter Group: Model 705-S Stir Fry Cutter
Basket assembly includes blades, spacers, traction
drive and stripper of heavy-duty stainless steel.
Safety Cover Interlock: Electromagnetic interlock
deactivates the tenderizer/stir fry cutter when the
safety cover is raised so the unit will not run.
On/Off Switch: Highly reliable, on/off, manual,
rocker type switch.
Cord and Plug: Attached 6-foot, flexible, 3-wire cord
and plug for grounded receptacle.
Warranty: All parts, service and travel coverage for
one year, excluding wear items.
As we continually strive to improve our products, specifications
are necessarily subject to change without notice.
Model No. Product 705-S Slice Output Product Dimensions
Capacity Thickness Speed Width A Depth B Height C
705 1-1/4” (32 mm) thick 1/2”, 3/8” 120 RPM 16-1/8” 13-5/8” 16-1/4”
7-7/8” (200 mm) wide (13, 10 mm) (410 mm) (346 mm) (413 mm)
Motor Electrical Weight Box Dimensions
Width Depth Height
1-speed 115/60/1 Net 62 lbs. (28 kg) 20-1/2” 19” 19”
1/2 HP Ship 70 lbs. (32 kg) (521 mm) (483 mm) (483 mm)
A
C
B
10”
(254 mm)
15-1/2”
(394 mm)
705 Tenderizer Technical Manuals Page 4 of 34
