Title: A. Ice Dispenser Assembly Model: DCM-500BWH
Index
No. Description
Material or
Model Number Part Number
Required Number
T-0
T-1
U-0
U-1
V-0 V-1 V-2 V-3 V-4
10 Gasket 429758-01 2 2 2 2 2 2 2
11 Spout (B) 208807-01 1 1 1 1 1 1 1
11a Thumbscrew 415949G11 4 4 4 4 4 4 4
12 Packing (B) Spout 427196-01 1 1 1 1 1 1 1
13 Rear Panel GS 2A2471-01 1 1 1 1 1 -
2A5402-01 1 1
13a Truss Head Screw 4×8, SS 7C32-0408 4 4 4 4 4 -
FT Screw 7F32-0408 4 4
14 Panel (Lo) SS 2A0699G01 1 1 1 1 1 1 1
14a FT Screw 4×8, SS 7F32-0408 6 6 6 6 6 6 6
15 Apron Panel (A) SS 2A0720-01 1 1 1 1 1 1 1
15a Truss Head Screw 4×8, SS 7C32-0408 4 4 4 4 4 -
FT Screw 7F32-0408 2 2
15b T2 Screw 4×8, SS 7P32-0408 2 2
16 Grille 2A0827G01 1 1 1 1 1 1 1
17 Bin Cover 2A0880A02 1 1 1 1 1 1 1
17a Thumbscrew 415949G12 4 4 4 4 4 4 4
18 Drip Tray 2A2591G01 1 1 1 1 1 1 1
18a Truss Head Screw 4×8, SS 7C32-0408 4 4 4 4 4 -
FT Screw 7F32-0408 4 4
19 Side Panel (L) SS 2A2624-01 1 1 1 1 1 -
2A6142-01 1 1
19a Truss Head Screw 4×8, SS 7C32-0408 6 6 6 6 6 -
FT Screw 7F32-0408 6 6
20 Side Panel (R) SS 2A2625-01 1 1 1 1 1 -
2A6141-01 1 1
20a Truss Head Screw 4×8, SS 7C32-0408 6 6 6 6 6 -
FT Screw 7F32-0408 6 6
21 Agitator SS 3A0895G01 1 1 1 1 1 1 1
22 Top Panel SS 3A2514G01 1 1 1 1 1 1 1
23 Auger (Dispense) SS 339192G01 1 1 1 1 1 1 1
24 Ice Chute 4A2204-01 1 1 1 1 1 1 1
24a Thumbscrew 415949G08 2 2 2 2 2 2 2
25 Wire Saddle 4A0338-01 2 2
26 Gear Motor Bracket SS 4A4308-01 1 1 1 1 1 1 1
26a Hex Head Bolt 8×12, SS 7B02-0812 3 3 3 3 3 3 3
26b Split Lock Washer M8, SS 7L22-0800 3 3
27 Drain Pan Bracket Assembly SS 4A4315G01 1 1 1 1 1 See "M. Frame
Assembly," items
6 and 6a
27a Hex Head Bolt 8×12, SS 7B02-0812 3 3 3 3 3
28 Drain Pan Assembly 4A4354G01 1 1 1 1 -
4A4354G02 1 1 1
28a Flat Washer M8, SS 7W22-0800 4 4 4 4 4 4 4
28b Allen Head Cap Screw 8×20, SS 7S12-0820 4 4 4 4 4 4 4
29 Heater (includes item 29) 4A2292-01 1 1 1 1 1 1 1
30 Spring 4A2292F01 1 1 1 1 1 1 1
31 Plug Housing 4A4002-01 2 -
412832-05 1 1 1 1 1 1
32 Reservoir Bracket 3A5675-01 1 1
32a FT Screw 7F32-0408 2 2
33 Bushing 428394-02 1 1
