Title: E. Control Box Assembly Model: DCM-500BAH, DCM-500BWH
Index
No. Description
Material or
Model Number Part Number
Required Number
T-0
to
U-0
U-1
V-0
V-1
V-2
V-3
V-4
1 Control Box (for mounting
hardware, see item E1 in "A. Ice
Dispenser Assembly.")
2A1638G01 1 -
2A2614G01 1 -
2A2614G02 1 -
2A5458-02 1
2 Control Box Cover 429931-01 1 1 1 -
4A5054-01 1
2a Truss Head Screw 4×6 7C31-0406 2 2 2 -
FT Screw 7F31-0406 2
3 Starter
GE# 3ARR3CT5M5
4A1107-11 1 1 1 1
3a T2 Screw 4×8 7P31-0408 1 1 1 1
4 Run Capacitor 15MFD, 370VAC 3A2005-08 1 1 -
35MFD, 440VAC 3A2005-12 1 1
5 Start Capacitor 243-292MFD,
115VAC
3A0076-10 1 1 -
243-292MFD,
165VAC
3A0076-20 1 1
6 Strap 4A2262-02 1 1 1 1
6a T2 Screw 4×8 7P31-0408 1 1 1 1
7 Transformer 2U0042-02 1 1 1 1
7a T2 Screw 4×8 7P31-0408 2 2 2 2
8 Control Board 2A1592-01 1 1 1 1
9 Board Support 4A0336-03 4 4 4 4
10 Capacitor-Gear Motor 20MFD, 350VAC 4A4319-01 1 1 1 1
10a T2 Screw 4×8 7P31-0408 1 1 1 1
11 Gear Motor Relay 120VAC 406132-07 1 1 1 1
11a Tapping Screw 3×8 431415-01 2 2 2 2
12 Power Protect Relay 220/240VAC 418271-05 1 1 1 1
12a Tapping Screw 3×8 431415-01 2 2 2 2
13 Water Control Relay 24VAC 406132-03 1 1 1 1
13a Tapping Screw 3×8 431415-01 2 2 2 2
14 Bushing 420472-03 1 1 1 1
15 Switch Bracket 4A1013-01 1 -
15a T2 Screw 4×8 7P31-0408 2 -
16 Microswitch 4A2546-01 1 -
16a Spacer 429933-01 1 -
16b Tapping Screw 3×14 431415-02 2 -
17 Fuse Holder 4A0892-01 1 1 1 -
4A3449-02 2
18 Fuse AGC-1 1A,
250VAC
4A0893-01 1 1 1 1
19 Fuse Holder 4A0892-02 2 2 2 -
4A3449-01 1
20 Fuse GMC-500mA,
250VAC
4A0893-02 1 1 1 1
21 Fuse GMD 2.0A,
250VAC
4A0893-05 3 3 3 3
22 Rocker Switch 4A0558-01 1 1 1 1
30
