Title: M. Frame Assembly Model: DCM-500BAH, DCM-500BWH
Index
No. Description
Material or
Model Number Part Number
Required Number
T-0
to
V-2
V-3
V-4
1 Base GS 3A0614G01 1 -
3A5637G01 1
2 Front Frame GS 2A0665G01 1 -
2a FT Screw 4×8, SS 7F32-0408 3 -
3 Rear Frame GS 2A0666-01 1 -
3a FT Screw 4×8, SS 7F32-0408 3 -
4 Separator GS 3A0615-01 1 -
3A5656-01 1
4a Truss Head Screw 4×8 7C31-0408 2 -
FT Screw 4×8, SS 7F32-0408 4
5 Side Frame-R GS 2A4116-01 1 -
5a Truss Head Screw 4×8 7C31-0408 5 -
6 Drain Pan Bracket Assembly GS 2A0667G01 1 -
2A5389G01 1
6a Truss Head Screw 4×8 7C31-0408 4 -
FT Screw 4×8, SS 7F32-0408 2
7 Side Frame (Up) GS 3A0616G01 1 -
7a Truss Head Screw 4×8 7C31-0408 4 -
8 Center Panel GS 3A0617G01 1 -
3A5810G02 1
8a Truss Head Screw 4×8 7C31-0408 2 -
FT Screw 4×8, SS 7F32-0408 2
9 Side Frame A GS 3A5639-01 1
9a FT Screw 4×8, SS 7F32-0408 4
10 Side Frame B GS 3A5641-01 1
10a FT Screw 4×8, SS 7F32-0408 6
11 Side Frame Assembly C GS 3A5768G01 1
11a FT Screw 4×8, SS 7F32-0408 2
12 Side Frame Assembly D GS 3A5769G01 1
12a FT Screw 4×8, SS 7F32-0408 3
13 Side Frame Assembly E GS 3A5809G01 1
13a FT Screw 4×8, SS 7F32-0408 3
14 Frame A GS 3A5644-01 1
14a FT Screw 4×8, SS 7F32-0408 5
15 Frame B GS 3A5645-01 1
15a FT Screw 4×8, SS 7F32-0408 4
16 Center Frame A GS 3A5646-01 1
16a FT Screw 4×8, SS 7F32-0408 4
17 Drip Tray Bracket 3A5667-01 2
17a FT Screw 4×8, SS 7F32-0408 4
