UC100 Installation Manual
© 2008, IMI Cornelius Inc. - 1 - Publication Number: 621054211INS
INSTALLATION MANUAL
Starbucks UC100 Progate Ice Dispenser
D
ESCRIPTION
The UC100 Progate ice dispenser solves your ice service needs in a sanitary, space saving, economical
way. Designed to be manually filled with Ice-O-Matic half cube ice.
CAUTION: The dispenser cannot be used with crushed or flaked ice. Use of bagged ice
which has frozen into large chunks can void warranty. The dispenser agitator is not
designed to be an ice crusher. Use of large chunks of ice which “jam up” inside the hopper
will cause failure of the agitator motor and damage to the hopper.
Specifications
Model: UC100 Progate
Ice Storage: 100 lbs
Electrical: 120/1/60, 3 amps total unit draw
CO
2
or Air Requirements: 100 psi max to unit regulated to 50 psi (3.4 bar) to Progate ice gate system
Dimensions: 24” Wide
30” Deep
27” Below Countertop
28” Above Countertop
Release Date: January 24, 2008 www.cornelius.com Revision: A
